They sent me a model DSA815-TG which spans to 1.5 GHz, but other models in the series go to 7.5 GHz. Saelig, their US distributor, loaned me one for evaluation, and the bottom line is that this baby packs a ton of capability into one small and inexpensive package. These are not available for the DS4000E Series.Rigol has a new low-cost spectrum analyzer (SA). BW3T5-MSO/DS4000 Bandwidth Upgrade from 350 MHz to 500 MHz for models MSO/DS403x (2/4 channel).BW2T5-MSO/DS4000 Bandwidth Upgrade from 200 MHz to 500 MHz for models MSO/DS402x (2/4 channel).BW2T3-MSO/DS4000 Bandwidth Upgrade from 200 MHz to 350 MHz for models MSO/DS402x (2/4 channel).The following three upgrades are available: It is mandatory that the latest Firmware is installed. Rigol offers three upgrade options for both, DS models (Digital Storage Oscilloscopes) and MSO models (Mixed Signal Oscilloscopes) of the 4000 Series. The DS4000(E) Oscilloscopes can be upgraded with decoding functions (RS232, I☬, SPI, CAN, FlexRay) and advanced trigger options (Windows, Nth Edge, Video / HDTV, Delay, TimeOut, Duration und USB) by entering a serial code. Rigol alternatively offers the MSO4000 series with an additional built-in 16 channel logic analyzer.Īttention: All DS/MSO4000 are equipped with a new fan which is much more quiet than before! Extendibility
The devices are available with 2 and 4 built-in channels and have 4 bandwidth variants each (100, 200, 350 and 500 MHz). The economic models DS4014E and DS4024E provide a sample rate of 2 GSa/s (per channel) and 14 Mpts memory (per channel). The Rigol DS4000 series consists of 8 high level Oscilloscopes for professional operation, which come off very well compared to higher prices models of other brands.Īll models of the DS4000 provide a sample rate of 4 GSa/s, 140 Mpts memory(!), a 9” (22,9 cm) TFT-color display, as well as professional measurement and mathematical functions.
